SARS-CoV-2 (Coronavirus) Detection Workflow For Research Use Only

Wed 17 Feb, 2021

Overview of the SARS-CoV-2 (Coronavirus) Detection Process

In December 2019 the novel SARS-CoV-2 (formerly named 2019-nCoV) was identified in Wuhan, the capital of China’s province Hubei. Based on its rapid spreading with more than 105,000,000 confirmed cases by beginning of February 2021 the World Health Organization declared the outbreak a public health emergency of international concern.

Important facts:

  • SARS-CoV-2: (+) ss-RNA virus
  • Related to SARS-CoV and MERS-CoV
  • Detection based on basis of PCR

Analytik Jena offers a broad product portfolio in the field of nucleic acid extraction and PCR or real-time PCR with both extraction kits and the necessary equipment. For research purposes for the detection of SARS-CoV-2 the following workflow is suggested.

1. Sample Collection

In principle, respiratory material such as nasopharyngeal and oropharyngeal swabs are suitable for the detection of respiratory pathogens. For more detailed information, recommendations of the WHO or other institutions should be observed.
Serum can also be used for serological tests, acute and convalescence samples.

2. Nucleic Acid Extraction

Analytik Jena offers a choice of extraction platforms and related extraction kits for extraction of viral RNA from swabs, cell free body fluids (e.g. serum, plasma, cerebrospinal fluid) and more. The product line innuPREP AniPath allows the simultanous extraction of both bacterial and viral DNA and/or RNA from respective starting materials. A detailed overview is shown in the table below.

HandlingSample throughputExtraction platformExtraction kit
NameKey features
ManualLow-Up to 12 samples / 25 min

innuPREP Virus TS RNA Kit
innuPREP Virus DNA/RNA Kit



Automated

MiddleInnuPure C16 touchUp to 16 samples / 31 - 84 min
Extraction platform only

innuPREP AniPath DNA/RNA Kit - IPC16, non-filled
innuPREP AniPath DNA/RNA Kit - IPC16
innuPREP Virus DNA/RNA Kit - IPC16, non-filled
innuPREP Virus DNA/RNA Kit - IPC16

HighCyBio FeliXUp to 96 samples / 62 - 73 min
Extraction platform + liquid handling
(e.g. preparation of PCR)

innuPREP AniPath DNA/RNA Kit – FX*
innuPREP Virus TS RNA Kit 2.0 - FX
innuPREP Virus DNA/RNA Kit - FX

HighKingFisher FlexUp to 96 samples / 60 min
Extraction platform only
innuPREP AniPath DNA/RNA Kit - KFFLX
innuPREP RNA Virus PLUS Kit – KFFLX

* Release planned for mid 2021

3. Amplification and Detection

Molecular assays to detect SARS-CoV-2 have been developed and are accessible through the homepage of the WHO. Furthermore, several commercial kits based on real-time PCR
are available. The table below shows all available detection kits which are tested on qTOWER³ and/or qTOWER³ 84.

Company nameAssay nameCE-IVD/ FDA EUA*Dye/ configuration/ target
Assays detecting SARS-CoV-2
Altona DiagnosticRealStar® SARS-CoV-2 RT-PCR Kit 1.0 RUO-FAM: Color Module 1 (E gene)
VIC: Color module 2 (IC)
Cy5: Color module 5 (S gene)
BGI GenomicsReal-Time Fluorescent RT-PCR Kit for Detecting SARS-2019-nCoV-FAM: Color Module 1 (N-CoV)
VIC/HEX: Color Module 2 (IC)
EuroImmunEuroRealTime SARS-CoV-2CE IVD (qTOWER3)FAM: Color Module 1 (ORF1ab and N gene)
HEX: Color Module 3 (IC)
Fosun Pharma USAFosun COVID-19 RT-PCR Detection Kit-FAM: Color Module 1 (ORF1ab)
HEX: Color Module 2 (N gene)
ROX: Color Module 4 (E gene)
Cy5: Color Module 5 (IC)
IDEXXWater SARS-CoV-2 RT-PCR Test-FAM:  Color Module 1 (N1 and N2)
HEX: Color Module 2 (IC)
IngentixViroReal® Kit SARS-CoV-2 & SARSCE IVD (qTOWER3)FAM: Color Module 1 (RdRp)
Cy5: Color Module 5 (IC)
Inno-Train Diagnostik GmbHCovid-19 FluoGene QCE IVD (qTOWER3)FAM: Color Module 1 (N1 gene)
VIC/JOE: Color Module 2 (M gene)
ROX: Color Module 4 (IC)
MikrogenampliCube Coronavirus SARS-CoV-2-FAM: Color Module 1 (E gene)
HEX: Color Module 2 (ORF1a)
Cy5: Color Module 5 (IC)
ampliCube Coronavirus Panel-FAM: Color Module 1 (MERS-CoV)
HEX: Color Module 2 (SARS-CoV,SARS-CoV-2, Bat SARS-like CoV)
ROX: Color Module 4 (HCoV)
Cy5: Color Module 5 (IC)
Perkin ElmerSARS-CoV-2 RT-qPCR Reagent kitCE IVD (qTOWER3)FAM: Color Module 1 (N gene)
HEX: Color Module 2 (ORF1ab)
Cy5: Color Module 5 (IC)
New Coronavirus Nucleic Acid Detection KitFDA EUA (qTOWER3)
FDA EUA (qTOWER3 84)
FAM: Color Module 1 (N gene)
ROX: Color Module 4 (ORF1ab)
HEX: Color module 2 (IC)
PrimerDesignCoronavirus (COVID-19) FAM: Color Module 1 (RdRp)
VIC: Color module 2 (IC)
Procomcure BiotechPhoenixDx® SARS-CoV-2 IVDCE IVD (qTOWER3)FAM: Color Module 1 (E gene)
FAM: Color Module 1 (RdRp)
R-BiopharmRIDA®GENE SARS-CoV-2 RUO-FAM: Color Module 1 (E gene)
VIC: Color module 2 (IC)
RTA LaboratoriesDiagnovital SARS-CoV-2 MultiplexFDA EUA (qTOWER3) pendingFAM: Color Module 1 (N gene, ORF1ab)
HEX: Color Module 2 (IC)
SeegeneAllplex™ 2019-nCoV Assay-FAM: Color Module 1 (E gene)
HEX: Color Module 2 (IC)
ROX: Color Module 4 (RdRP gene)
Cy5: Color Module 5 (N gene)
Shimadzu2019 Novel Coronavirus Detection Kit -FAM: Color Module 1 (N1 gene)
ROX: Color Module 4 (N2 gene)
Cy5: Color Module 5 (IC)
Siemens healthineers /
Fast-Track Diagnostic
FTD SARS-CoV-2 Assay (RUO)-FAM: Color Module 1 (ORF1ab and N gene)
Cy5: Color Module 5 (IC)
SolGentDiaPlexQ Novel Coronavirus (2019-nCOV) Detection Kit-FAM: Color Module 1 (N gene)
VIC: Color Module 2 (ORF1a)
Texas Red: Color Module 4 (IC)
TIB MOLBIOLTIB MOLBIOL LightMix® Modular SARS-CoV-2 (COVID19) RdRP -FAM: Color Module 1 (RdRP gene)
Cy5: Color module 5 (IC)
TIB MOLBIOL LightMix® Modular SARS-CoV.2 (COVID19) E gene -FAM: Color Module 1 (E gene)
Cy5: Color module 5 (IC)
Wells BiocareGENE™ COVID-19 RT-PCR kit-FAM:  Color Module 1 (N gene)
ROX: Color Module 4 (IC)
Cy5: Color Module 5 (RdRp)
careGENE™ N-Cov RT-PCR Kit-FAM:  Color Module 1 (E gene)
ROX: Color Module 4 (IC)
Assays detecting SARS-CoV-2 mutations
TIB MOLBIOLTIB MOLBIOl VirSNiP SARS-CoV-2 Spike 501Y-FAM: Color Module 1 (SARS Spike 501Y)
Inno-Train Diagnostik GmbHCovid-19 FluoGene Q N501Y (RUO)-

FAM: Color Module 1 (N1 gene)
VIC/JOE: Color Module 2 (M gene)
ROX: Color Module 4 (IC)
Cy5: Color Module 5 (S N501Y)

Assays detecting SARS-CoV-2 and Influenza viruses
EuroImmunEURORealTime SARS-CoV-2/Influenza A/BCE IVD (qTOWER3)FAM: Color Module 1 (ORF1ab and N gene)
ROX: Color Module 4 (Influenza A)
Cy5: Color Module 5 (Influenza B)
HEX: Color Module 3 (IC)
IngentixViroReal® Kit SARS Coronavirus & Influenza A/BCE IVD (qTOWER3)FAM: Color Module 1 (SARS)
VIC: Color module 2 (Influenza A/B)
Cy5: Color Module 5 (IC)
MikrogenampliCube Respiratoty Flu & SARS-CoV-2-FAM: Color Module 1 (Influenza-A)
HEX: Color Module 2 (Influenza-B)
ROX: Color Module 4 (ORF1a)
Cy5: Color Module 5 (IC)
Cy5.5: Color Module 6 (E gene)
R-BiopharmRIDA®GENE Flu & SARS-CoV-2 RUO-FAM: Color Module 1 (Influenza A/B)
VIC: Color Module 2 (ICR)
ROX: Color Module 4 (E gene)
Cy5: Color Module 5 (RdRp gene)
Assays particularly tested for wastewater samples**
EuroImmunEuroRealTime SARS-CoV-2CE IVD (qTOWER³)FAM: Color Module 1 (ORF1ab and N gene)
HEX: Color Module 3 (IC)
IDEXXWater SARS-CoV-2 RT-PCR Test-

FAM: Color Module 1 (N1 and N2)
HEX: Color Module 2 (IC)

Inno-Train Diagnostik GmbHCovid-19 FluoGene QCE IVD (qTOWER³)FAM: Color Module 1 (N1 gene)
VIC/JOE: Color Module 2 (M gene)
ROX: Color Module 4 (IC)
Inno-Train Diagnostik GmbHCovid-19 FluoGene Q N501Y (RUO)-FAM: Color Module 1 (N1 gene)
VIC/JOE: Color Module 2 (M gene)
ROX: Color Module 4 (IC)
Cy5: Color Module 5 (S N501Y)
Zymo ResearchQuick SARS-CoV-2 Multiplex Kit-HEX: Color Module 2 (N gene)
Quasar670: Color Module 5 (IC)

*Please note that products of Analytik Jena GmbH listed here are not explicitly marked as CE IVD and are exclusively intended for research purposes. The validation of the kits was performed by the assay manufacturers themselves on qTOWER devices and was subsequently CE IVD or FDA EUA certified.

** Wastewater samples were preparaed according to the workflow established by Analytik Jena. Real-time PCR using the indicated assay was implemented on qTOWER3.

The PCR set up can be pipetted by a liquid handling platform like CyBio FeliX . Using PCR workstations or cabinets increases maximum safety and minimizes contamination risks. Single
components such as qPCR Master Mixes and Reverse Transcription MasterMix are available via Analytik Jena as well. In general all Real-time PCR-based assays can be established on the qTOWER3 real-time thermal cycler family provided by Analytik Jena or similar. Information on further commercial qPCR assays for SARS-CoV-2 detection with confirmed compatibility on qTOWER3 devices is available on request.
