AOX Autosampler Series The Right Solution for Any Task

  • Wide application range – AOX column method
  • Cost-effective solutions for small sample series
  • High throughput speed – up to 112 samples in a run
  • Flexibility – two functions one system
  • Maximum safety in horizontal AOX analysis – boat sensor

AOX Sampler for Small and Large Sample Series

The autoX samplers are available in different versions. This allows you to optimally adapt the multi X 2500 to the requirements of your laboratory operation, relevant analysis standards and sample throughput. The autoX series autosamplers allow flexible automation. From small AOX sample series in vertical up to multi-matrix variants for introduction of large series of AOX, EOX and TOX samples in vertical or horizontal operation.

Download Product Information

Intelligent flexibility for high sample throughput

autoX 112

Universal sampler platform, suited for the automated direct introduction of up to 112 AOX samples acc. column method, resp. up to 35 organic solids like derived fuels in quartz sample boats, or 112 EOX resp. other organic liquids like used oil.

  • Cost effcitive 4-in-1 automation solution suitale for in vertical and horizontal operation mode
  • Flexible system configuration, accessory kits for dosing of solids/AOX (35 pos.), liquids/EOX (112 pos.), TOC (60 pos.), direct dosing of enriched AOX charcoal out of the columns(112 pos.)
  • Liquids up to 500 μL (direct injection by μL-syringe), solids up to 110 mg resp. AOX samples acc. batch and column method (boat dosing by gripper)
  • Easy operation software -controlled, automatic recognition of present accessory kit
  • High sample throughput and significantly increased up-time due to direct dosing of AOX samples awithout the columnUnlimited flexibility, upgradable at any later time by suited extension-kits
  • Reduced maintenance effort for analysis of challenging EOX extracts and used oil – automatic rinsing cycles with sample and pure solvent, sealed niveau vessel for waste disposal

autoX 36 / autoX 36d

The automatic samplers autoX 36 / 36d are the ideal solution for comfortable processing of small sample numbers. They are suited to introduce up to 36 samples within one sequence in the instrument. The standard version autoX 36 can process AOX samples prepared according batch and column method. The special version autoX 36d enables the direct feeding of charcoal into the combustion system by pushing it out of the columns. As an option, it can be extended by the standard 36 position tray, enabling intrduction of the entire columns.

Products

Technical Data

Dimension (width x depth x height)

autoX 112 sampler
450-126.690

510 mm x 500 mm x 280 mm

Standards

  • APHA SM 5320 B
  • ASTM D4744
  • DIN 38409-22
  • DIN 38414-17
  • DIN 38414-18
  • DIN EN 1485
  • DIN EN 16166
  • DIN EN ISO 9562
  • EPA 1650C
  • EPA 450.1
  • EPA 9020B
  • EPA 9023
  • NEN 6402
  • OENORM 6614

Order Information

Order number

Description

450-126.690 autoX 112 sampler for flexible automation of AOX, solids, EOX, TOC and liquids dosing
450-126.412 autoX 36 AOX sampler for vertical operation mode
450-126.408 autoX 36d AOX sampler with direct feed capability

Accessories

AOX rack autoX 112 450-889.603
Turntable for 36 quartz containers 450-126.414
EOX rack autoX 112 450-889.528
AOX / solids rack MMS 5000 / autoX 112 450-889.523
Boat sensor for MMS and autoX 112 sampler 450-889.204
Cover for multi matrix sampler 450-900.408
TOC rack autoX 112 450-889.529
Filling device for activated carbon (20 mg) 402-880.212
Adjustment tool for solids rack MMS / autoX 112 402-889.837

Consumables

402-889.645 Quartz container, thin-walled, 18 x 8 mm
402-880.609 Set of 100 disposable tubes 18 x 8 mm, filled
402-880.610 Set of 100 disposable tubes for AOX 18 x 6 mm, filled
402-810.025 Activated carbon for AOX batch method
402-810.004 Activated carbon for AOX column method
402-823.056 Needles, I.D. 0.35 mm for syringes
402-880.008 Quartz container, empty
402-823.079 Removable needles for 50 and 100 µL syringes
402-889.206 Septum for solvent vessel
402-889.557 Set sealing disks , 17 mm
402-889.534 Syringe 100 µL for MMS
402-889.594 Syringe 250 µL with vent
402-889.593 Syringe 500 µL with vent
402-886.248 Waste hose for autosampler
